Cornice Designs
On this page you will find over 97 designs.
Dimensions, particularly imperial are approximate only. Use with caution.
To view PDF fact sheets for the individual cornice styles, please click the learn more button or image within the relevant section.
Victorian in Style.
Projection 115mm
Depth 100mm
Plain Run Profile.
Cast length 3100mm.each.
We are making new moulds! Top members and bottom are being made thicker
Projection 70mm (3 inches)
Depth 95mm (4 inches)
Leaf Enriched Profile.
Cast length 3050mm (10 foot 0 inches) each.
Georgian in Design.
Projection 122mm (5 inches)
Depth 122mm (5 inches)
Plain Run (Drip) Profile.
Cast length 3100mm (10 foot 2 inches) each.
Georgian in Design.
Projection 93mm (4 inches)
Depth 100mm (4 inches)
Plain Run (Drip) Profile.
Cast length 3050mm (10 foot 0 inches) each.
Georgian in Design.
Projection 50mm (2 inches)
Depth 50mm (2 inches)
Plain Run (Drip) Profile.
Cast length 3150mm (10 foot 4 inches) each.
Georgian in Design.
Projection 110mm (4.55 inches)
Depth 120mm (5 inches)
Plain Run (Drip) Profile.
Cast length 3250mm (10 foot 8 inches) each.
Victorian in Design.
Projection 120mm (5 inches)
Depth 160mm (6.5 inches)
Plain Run (Drip) Profile.
Cast length 3100mm (10 foot ) each.
Regency in Design. (I think)
Projection 122mm (5 inches)
Depth 122mm (5 inches)
Plain Run (Drip) Profile.
Cast length 3100mm (10 foot 2 inches) each.
Projection 150mm (6 inches)
Depth 150mm (6 inches)
Plain Run (Drip) Profile.
Cast length 3100mm (10 foot 2 inches) each.
Victorian in Design.
Projection 65mm (2.5 inches)
Depth 90mm (4 inches)
Plain Run Profile.
Cast length 3250mm (11 foot 3 inches) each.
Projection 55mm (2 inches)
Depth 90mm (4 inches)
Plain Run Profile.
Cast length 3200mm (10 foot 6 inches) each.
Georgian in Design.
Projection 90mm (4 inches)
Depth 110mm (4 inches)
Egg & Dart Enriched Profile.
Cast length 3270mm (10 foot 8 inches) each.
Projection 110mm (4.5 inches)
Depth 120mm (5 inches)
Egg & Dart Enriched Profile.
Cast length 3250mm
(10 foot 8 inches) each.
Cornice 113 - Grosvenor
Projection 95mm (4 inches)
Depth 125mm (5 inches)Leaf Enriched Profile.
Cast length 3125mm (10 foot 3 inches) each.
This pattern is temporarily out of production – please enquire availability “on the day”.
Projection 95mm (4 inches
Depth 125mm (5 inches)
Leaf Enriched Profile.
Cast length 3125mm (10 foot 3 inches) each.
This pattern is temporarily out of production – please enquire availability “on the day”.
Projection 95mm (4 inches)
Depth 104mm (4 inches)
Plain Run Profile.
Cast length 3500mm (11 foot 5 inches) each.
Projection 180mm. (c.7”)
Depth 170mm. (c.7”)
Length of Cast 3100mm. (10’2”)
Heavily Enriched Profile
Victorian in Design.
Projection 75mm (3 inches)
Depth 110mm (4.5 inches)
Plain Run Profile.
Cast length 3050mm (10 foot 0 inches) each.
Islamic in Design.
Projection 85mm (3.5 inches)
Depth 155mm (6 inches)
Very Heavily Enriched Profile.
Cast length 3250mm (10 foot 8 inches) each.
Contemporary / Modern in Design – possibly Deco
Projection 140mm (5.5 inches)
Depth 105mm (4 inches)
Cast length 3450mm (11 foot 4 inches) each.
Modern in Design.
Projection 50mm (2 inches)
Depth 170mm (7 inches)
Plain Run Profile.
Cast length 3250mm (10 foot 8 inches) each.
Projection 60mm (2 inches)
Depth 90mm (3.5 inches)
Plain Run Profile.
Cast length 3500mm (11 foot 5 inches) each.
Circa 1900 North American in Design.
Projection 70mm (3 inches)
Depth 100mm (4 inches)
Plain Run Profile.
Cast length 3040mm (10 foot 0 inches) each.
Late Victorian in Design.
Projection 220mm (8.5 inches)
Depth 145mm (6 inches)
Plain Run Profile.
Cast length c3350mm (10 foot 11 inches) each.
1900 Approx North American in Design.
Projection 205mm (8 inches)
Depth 200mm (8 inches)
Plain Run Profile.
Cast length 3000mm (10 foot 0 inches) each.
Georgian in Style but Late Victorian in Design.
Projection 80mm (3 inches)
Depth 110mm (4.5 inches)
Plain Run Profile.
Cast length 3000mm (10 foot 0 inches) each.
Generally Regency in Style.
Projection 120mm (5 inches)
Depth 160mm (6.5 inches)
Honeysuckle Enriched Profile.
Cast length 3300mm (10 foot 10 inches) each.
Projection 115mm (4.5 inches)
Depth 95mm (4 inches)
Plain Run Profile.
Cast length 3100mm (11 foot 3 inches) each.
Projection 120mm (5 inches)
Depth 85mm (3.55 inches)
Plain Run Profile.
Cast length 3290mm (10 foot 9 inches) each.
Projection 165mm (6.5 inches)
Depth 165mm (6.5 inches)
Plain Run Profile.
Cast length 3050mm (10 foot 0 inches) each.
Georgian in Design.
Projection 180mm (7 inches)
Depth 180mm (7 inches)
Dentil Enriched Profile.
Cast length 3400mm (11 foot 1 inches) each.
Georgian in Design.
Projection 54mm (2 inches)
Depth 115mm (4.5 inches)
Plain Run Profile.
Cast length 3325mm (10 foot 9 inches) each.
Projection 65mm (2.5 inches)
Depth 200mm (8 inches)
Flute Enriched Profile.
Cast length 3200mm (10 foot 6 inches) each.
Victorian in Design.
Projection 200mm (8 inches)
Depth 100mm (4 inches)
Plain Run Profile.
Cast length 3100mm (10 foot 2 inches) each.
Projection 100mm (4 inches)
Depth 100mm (4 inches)
Plain Run Profile.
Cast length 3500mm (11 foot 6 inches) each.
Projection 160mm (6.5 inches)
Depth 130mm (5 inches)
Plain Run Profile.
Cast length 3250mm (10 foot 8 inches) each.
Art Deco in Design.
Projection 150mm (6 inches)
Depth 160mm (6 inches)
Geometric Enriched Profile.
Cast length 3300mm (10 foot 10 inches) each.
Art Deco in Design.
Projection 207mm (8 inches)
Depth 250mm (10 inches)
Geometric Enriched Profile.
Cast length 3325mm (10 foot 6 inches) each.
Projection 186mm (7.5 inches)
Depth 140mm (5.5 inches)
Plain Profile.
Cast length 3200mm (10 foot 6 inches) each.
Projection 210mm (8.5 inches)
Depth 205mm (8 inches)
Plain Profile.
Cast length 3050mm (10 foot 0 inches) each.
Projection Ceiling Across 200mm
Wall Depth 225
Cornice Length 3.160m
Projection 250mm (10 inches)
Depth 260mm (10.5 inches)
Plain Profile.
Cast length 3200mm (10 foot 6 inches) each
Georgian in Design.
Projection 100mm (4 inches)
epth 112mm (4.5 inches)
Dentil Enriched Profile.
Cast length 3050mm (10 foot 0 inches) each.
Projection 75mm (3 inches) 144
Depth 65mm (2.5 inches)
Rope Enriched Profile.
Cast length 3050mm (10 foot 0 inches) each.
Georgian in Style.
Projection 122mm (5 inches)
Depth 122mm (5 inches)
Egg & Dart Enriched Profile.
Cast length 3050mm (10 foot 0 inches) each.
Modern Victorian in Style.
Projection 100mm (4 inches)
Depth 107mm (4 inches)
Plain Profile.
Cast length 3200mm (10 foot 6 inches) each.
Projection 104mm (4 inches)
Depth 104mm (4 inches)
Plain Profile.
Cast length 3400mm (11 foot 1 inches) each.
Projection 140mm (5.5 inches)
Depth 90mm (3.5 inches)
Plain Profile.
Cast length 3200mm (10 foot 6 inches) each.
William & Mary Style
Projection 80mm (3 inches)
Depth 110mm (4.5 inches)
Leaf Enriched Profile.
Cast length 3400mm (11 foot 2 inches) each.
Early Victorian from a circa 1840 home in Style.
Projection 60mm (2.5 inches)
Depth 105mm (4.2 inches)
Plain Profile.
Cast length 3500mm? (11 foot 6 inches)? each.
This design can go both ways around.
Victorian in Design
Projection 150mm (6 inches)
Depth 100mm (4 inches)
Plain Profile.
Cast length 3500mm (11 foot 5 inches) each.
Regency in Style
Projection 120mm (5 inches)
152
Depth 115mm (4.5 inches)
Husk Enriched Profile.
Cast length 3370mm (11 foot 0 inches) each.
Projection 125mm (5 inches)
Depth 120mm (5 inches)
Rope Enriched Profile.
Cast length 3000mm (10 foot 0 inches) each.
Projection 140mm (5 inches)
Depth 175mm (7 inches)
Leaf Enriched Profile.
Cast length 3220mm (10 foot 6 inches) each.
Projection 125mm (5 inches)
Depth 55mm (2 inches)
Plain Profile.
Cast length 3130mm (10 foot 4 inches) each.
Projection 110mm (5.5 inches)
Depth 130mm (5 inches)
Leaf Enriched Profile.
Cast length 3120mm (10 foot 2 inches) each.
Projection 120mm (5 inches)
Depth 50mm (2 inches)
Plain Profile.
Cast length 3600mm (12 foot 0 inches) each.
Modern in Style
Projection 215mm (8.5 inches)
Depth 55mm (2 inches)
Plain Profile.
Cast length 3600mm (12 foot 0 inches) each.
William & Mary Style
Projection 155mm (6 inches)
Depth 170mm (7 inches)
Heavily Enriched Profile.
Cast length 3100mm (10 foot 1 inch) each.
Projection 65mm (2 inches) 159
Depth 125mm (5 inches)
Wood Effect Face, Egg & Dart Enriched Profile.
Cast length 3000mm (10 foot 0 inches) each.
High Victorian Style
Projection 200mm (8 inches)
Depth 160mm (6.5 inches)
Plain Run Profile.
Cast length 3500mm (11 foot 6 inches) each.
High Victorian Style
Projection 190mm (7.5 inches)
Depth 140mm (5.5 inches)
Plain Run Profile.
Cast length 3500mm (11 foot 6 inches) each.
Learn More.
High Victorian Style
Projection 320mm (13 inches)
Depth 160mm (6.5 inches)
Plain Run Profile.
Cast length 3500mm (11 foot 6 inches) each.
High Victorian Style
Projection 178mm (7 inches) 163164
Depth 115mm (4.5 inches)
Plain Run Profile.
Cast length 3300mm (10 foot 10 inches) each.
Very Undercut
Victorian circa 1830 in Style
Projection 160mm (6.5 inches)
Depth 80mm (3 inches)
Bead Enriched Profile.
Cast length 3170m (10 foot 3 inches) each.
Cove in style.
Projection circa 130mm (circa 5 inches)
Depth 130mm (5 inches)
Plain Run Profile.
Cast length 3450mm (11 foot 4 inches) each.
Projection 160mm (5.5 inches)
Depth 90mm (3.5 inches)
Plain Run Stepped Profile.
Cast length 3600mm (11 foot 9 inches) each.
Projection 90mm (3.5 inches)
Depth 160mm (.5 inches)
Plain Run Stepped Profile.
This is Nr. 167 (immediately above) – inverted.
Cast length 3600mm (11 foot 9 inches) each.
Projection 120mm
Depth 70mm
Plain Run Stepped Profile.
Cast length 3600mm (11 foot 9 inches) each.
Projection 145mm
Depth 50mm
Plain Run Stepped Profile.
Cast length 3600mm (11 foot 9 inches) each.
Mid-Victorian in Style – Possibly circa 1860’s
Projection 150mm (6 inches)
Depth 175mm (7 inches)
Block Enriched Design.
Cast length 2.9m
Probably circa 1870 in date / style.
Projection 145mm (6 inches)
Depth 50mm (2 inches)
Plain Run Profile.
Cast length 3400mm (11 foot 2 inches) each.
Projection c.190mm (7.5 inches)
Depth 110mm (5 inches)
Plain Run Profile.
Cast length 3200mm (10 foot 6 inches) each.
Projection 200mm (8 inches)
Depth 140mm (5.5 inches)
Plain Run Stepped Profile.
Cast length 3400mm (11 foot 2 inches) each.
Projection 140mm (5.5 inches)
Depth 200mm (8 inches)
Plain Run Stepped Profile.
This nr. 171 above, simply put upside down / inverted.
Cast length 3400mm (11 foot 2 inches) each.
Projection 135 mm.
Depth 135 mm
Plain Run Stepped Profile.
Cast length c.3200mm (c.10 foot 6 inches) each.
Projection 200mm (8 inches)
Depth 83mm (3.25 inches)
Plain Run Stepped Profile.
Cast length 3400mm (11 foot 2 inches) each.
Projection 175mm (7 inches)
Depth 108mm (4.25 inches)
Plain Run Stepped Profile.
Cast length 3400mm (11 foot 2 inches) each.
Projection 165mm
Depth 145mm
Plain Run Stepped Profile.
Cast length 3.100mm (10 foot ) each.
Projection 100mm
Depth 105mm
Plain Run concaved Profile.
Cast length 3.100mm (10 foot ) each.
Projection 120mm
Depth 120mm
Plain Run concaved Profile.
Cast length 3.100mm (10 foot ) each.
Projection 158mm
Depth 158mm
Plain Run concaved Profile.
Cast length 3.100mm (10 foot ) each.
Projection 220mm
Depth 100mm
Plain Run concaved Profile.
Cast length 3.100mm (10 foot ) each.
Projection 70mm
Depth 180mm
Cast length 3100mm each.
Projection 148mm
Depth 148mm
Cast length 3100mm each.
New Design 2018
Projection 190mm
Depth 105mm
Cast length 3100mm each.
New Design 2018
Projection 195mm
Depth 150mm
Cast length 3100mm each.
New Design 2018
Projection 82mm (3 inches)
Depth 95mm (4 inches)
Egg and Dart Enriched Profile.
Cast length 3000mm (10 foot 0 inches) each.
Projection 112mm (4.5 inches)
Depth 122mm (5 inches)
Egg and Dart Enriched Profile.
Cast length 3000mm (10 foot 0 inches) each
Projection 125mm
Depth 115mm
Cast length 3.040 metres each.
Projection xxmm
Depth xxmm
Cast length xxmetres each.
Projection 95mm
Depth 100mm
Cast length 3010metres each.
Small Regency cornice moulding
manufactured in 3 metre lengths. John Nash
made significant alterations to the house in 1805;
this cornice is part of
that work. Can be used reversed in rooms with low ceilings
Projection 30mm
Depth 75mm
Projection 75mm
Depth 200mm
Cast length 3010mm
Projection 100mm (4 inches)
Depth 100mm (4 inches)
Egg and Dart Enriched Profile.
Cast length 2900mm (9 foot 8 inches) each.
Projection 115mm
Depth 120mm
Plain Profile.
Cast length 3100mm each.
We are making new moulds Top members and bottom are being made thicker!
Projection 175mm (7 inches)
Depth 130mm (5inches
Plain Profile.
Cast length 3050mm (10 foot) each
